Project Type: Commercial (Preschool & Educational Facility)

System Installed: Fire Alarm & Voice Evacuation System

Solutions Provided: Installed a 127-Point Addressable Fire Releasing Control Panel (PA) to manage and monitor all detection and notification devices across the facility. Integrated a 1-Zone 25-Watt Voice Evacuation Panel with Microphone to deliver clear voice instructions during emergencies. Installed Photoelectric Smoke Detectors and Fixed Temperature Heat Detectors for comprehensive fire detection. Added Speaker Strobes and Selectable Candela Ceiling Strobes (White) for both audible and visual emergency alerts. Mounted Addressable Dual-Action Pull Stations for manual activation. Installed Micro Input Modules, Flow Switch, and Tamper Switch Tie-ins for enhanced monitoring and system integration. Configured 10 Amp Power Supply and NAPCO StarLink Fire Communicator for dependable communication with the central monitoring station. Installed a 32-Character LCD Remote Annunciator for remote status display and quick access control. Included a Fire Alarm Drawing Box (Red) for secure storage of system documents and plans. Completed planning, permitting, installation, activation, and wiring in compliance with local and national fire codes.

Compliance & Inspection: System installation completed per NFPA standards and local authority requirements. Fire Alarm System successfully tested and ready for inspection and monitoring activation.

Project Type: Commercial (Elementary School)

System Serviced: Existing Fire Alarm System (Inspection & Monitoring Takeover)

Solutions Provided: Performed a complete annual inspection of the existing fire alarm system to verify all devices and notification appliances were fully operational and code-compliant. Successfully completed a fire panel takeover, integrating the school’s system into Fire Alarm Houston’s monitoring network. Installed and tested Photoelectric Smoke Detectors to ensure reliable early fire detection. Established monthly monitoring service for 24/7 supervision and prompt response to any alarm signals. Provided system optimization and documentation to ensure continued compliance with local fire safety codes.

Compliance & Inspection: System passed inspection and confirmed to be fully operational. Fire Alarm Houston now provides ongoing monitoring and maintenance support for Zahiya Academy’s fire safety system.

Project Type: Commercial (Gas Station & Travel Center)

System Installed: New Fire Alarm System

Solutions Provided: Installed DMP Fire Alarm Control Panel with 2 NAC for reliable system management. Integrated DMP Verizon LTE Cellular with 381-2 Cable for dependable communication and monitoring. Installed Ceiling Horn Strobes and Multi-Candela Ceiling Strobes for audible and visual emergency alerts. Provided Addressable Smoke Detectors for precise fire detection. Added Dual-Action Addressable Pull Stations for manual activation points. Deployed Monitor Module & Relay Module for expanded system functionality. Supplied and installed Fire Alarm Document Box (Red) for code compliance. Added Surge Protector to safeguard equipment. Installed 12v 7ah Sealed Lead Acid Backup Battery for uninterrupted system operation. Ran 16/2 Red Solid Plenum Fire Alarm Cable, 1000' for secure wiring connections. Handled Planning and Permitting to ensure compliance with local codes.

Compliance & Inspection: Successfully coordinated Inspection with the Fire Marshal and passed system verification. Delivered a fully functional, code-compliant fire alarm system tailored to the needs of a busy travel center and truck stop.

Project Type: Commercial (Beauty Salon & Spa)
System Serviced: Existing Fire Alarm System (Inspection & Monitoring)

Solutions Provided:
Annual Fire Alarm Inspection to confirm all devices and components were operating correctly and code-compliant. M2M Fire Alarm Communicator Installation for dependable alarm signal transmission to the central monitoring station. Horn Strobe Testing & Service to ensure proper visual and audible notifications in case of emergencies. 24/7 Fire Alarm Monitoring Service implemented for ongoing supervision and quick emergency response.

Compliance & Inspection:
Successfully completed the annual inspection with full system verification. Ensured the salon’s fire alarm system meets regulatory requirements and is ready for continuous monitoring.

Fire Alarm Houston delivered a fully integrated fire alarm system tailored to meet the safety requirements of the restaurant and in compliance with local fire codes.

Project Type: Commercial Fire Alarm System Installation

System Installed & Components: XF6-100 Fire Panel – core control system, Addressable Heat Detector (135°F, Replace H350), Addressable Smoke Detector – White, Addressable Dual-Action Pull Station, (Strobe Multi-Candela Ceiling Mount, White), (Wall-Mount Horn Strobe, White), Monitor Module for system integration,   18/2 Solid Plenum Fire Cable (Gray), (16/2 Red Solid Plenum Fire Alarm Cable, 1000'), Additional accessories as required.

Work Completed: Integration with pre-wired infrastructure. Installation of fire panel, detectors, pull stations, and notification appliances. Final wiring and system configuration. Coordination with authorities for compliance.

Compliance & Inspection: Full planning and permitting handled by Fire Alarm Houston. Inspection with the Fire Marshal conducted to ensure compliance with NFPA standards and local regulations.

Fire Alarm Houston installed a 127 Point Addressable Fire Alarm & Releasing Panel with a complete fire safety system, including:

AT&T LTE Cellular Communicator for monitoring and communication,   Photoelectric Smoke Detectors for reliable fire detection,   Heat Detectors (Fixed Temperature) for additional safety coverage,   Dual-Action Addressable Pull Stations for manual fire alarm activation,   Selectable Candela Ceiling Horn Strobes (White) for audio-visual notification,   16/2 Red Solid Plenum Fire Alarm Cable (1000') and 18/2 Solid Plenum Fire Cable (Gray) for compliant wiring.   All necessary accessories and components, Planning and Permitting handled by our team.   Inspection with the Fire Marshal to ensure the system met all local codes and regulations.

Project Type: Commercial (Community Clubhouse)
System Installed: Fire Alarm System
Fire Alarm Installation: Installed a DMP Fire Alarm Control Panel (500 Points) for advanced fire detection and system control.Integrated a Remote Annunciator for accessible fire system monitoring and alert.Installed Photoelectric Smoke Detectors for reliable smoke detection.Deployed Selectable Candela Ceiling Horn Strobes and Ceiling Strobes (White) for clear visual and audible emergency notifications.Installed 850D Pull Station with 711 Module for manual alarm activation.

Communication: Provided and installed DMP Verizon LTE Cellular Communicator with 381-2 Cable for secure signal transmission to monitoring services and access control systems.

Installation & Compliance: Completed all Installation, Activation, and Wiring for full system functionality. Managed Planning and Permitting to meet local fire code and inspection requirements.

This system ensures that Affinal Club House has a code-compliant, reliable, and efficient fire protection solution to safeguard the community.

Project Type: Commercial (Educational Institution)
System Installed: Fire Alarm System

Fire Alarm Installation:
IPA-100 (127 Point Addressable Fire Releasing Panel) and IPA-60 (60 Point Addressable Panel) for zone-based, intelligent fire detection and releasing capabilities. 10 AMP 6 NAC Power Supply (PSN-106) to support notification appliances and system expansion. 32 Character LCD Annunciator (RA-6075R) for real-time fire alarm status display. PAD 100 Dual-Action Pull Stations and PAD 100 Micro Input Modules for manual activation and device input monitoring. Addressable Photoelectric Smoke Detectors (SD355) and Fixed-Temperature Heat Detectors (SK-HEATHT) for early and accurate fire detection.

Notification Devices:
Low Frequency Sounders (HWLF) for code-compliant occupant alerting. Ceiling Mount Horn Strobes and Strobes (PC2W, SCW) including high candela (177CD) models (LFHS-177W) for effective visual and audio notifications.

Power, Wiring & Accessories:
18/2 and 16/2 Fire-Rated Wire (1000 FT Rolls) for system wiring. Underground Wire Run and Piping for secure cable routing. AC Hardwire Surge Protector (DIK-120HW) for equipment protection. Back Boxes, Screws, and Miscellaneous Accessories for a complete, secure setup.

Compliance & Inspection:
Completed Planning and Permitting to meet city fire codes and school safety regulations.
This advanced fire alarm system installation provides Everest Academy with a scalable, reliable, and code-compliant life safety solution that ensures protection across all areas of their academic facility.

Project Type: Commercial (Retail/Food Service)
System Installed: Fire Alarm SystemFire Alarm System Installation:
Installed a Fire Alarm Control Panel (FACP) to serve as the central unit for system control. Deployed Strobes and Horn Strobes for audible and visual emergency alerts. Supplied and installed a Fire Alarm Document Box for on-site compliance documentation. Used 16/2 Red Solid Plenum Fire Alarm Cable (1,000 ft) for all internal system wiring. Installed a 6 Amp 4 NAC Power Supply to support additional notification appliances. Routed wiring through Electric Metallic Tube (EMT) Conduit for enhanced durability and code compliance.

Security & Automation Integration by Alif Security LLC
After completing the fire alarm installation, the customer expressed interest in securing their space further with a security system. As a leading commercial security service provider in Texas, we referred them to our trusted partner, Alif Security LLC.

Alif Security LLC installed a 2GIG 2GIG-EDG-NA-VA Security and Automation Panel, enhancing both security and smart automation capabilities for the shop.

Compliance & Inspection:
Completed all necessary Planning and Permitting procedures to meet city regulations. Ensured that the entire system installation aligned with fire code standards for commercial food establishments.

This setup provides Cheaters Creamery with a reliable, code-compliant fire alarm system and a modern security panel to ensure safety, automation, and peace of mind.

Our team designed and installed a complete, 142-zone addressable fire alarm system tailored to the unique needs of the center's prayer halls, classrooms, and offices. The solution included:

Control and Monitoring:

• Centralized Fire Control Panel: A powerful panel with a 56 VA transformer serves as the brain of the system.

• Uninterrupted Power: A 12v 7ah sealed lead acid battery and a 10-amp power supply ensure the system remains online during a power outage.

• Remote Annunciator: An LCD display annunciator was installed for convenient at-a-glance system monitoring by facility staff.

Detection and Activation:

• Advanced Smoke Detectors: Strategically placed throughout the facility for early fire detection.

• Manual Pull Stations: 850D Pull Stations allow for immediate manual activation of the alarm by occupants.

Notification and Suppression:

• Horn Strobes: High-decibel horns with selectable candela strobes provide clear audio and visual alerts, meeting ADA accessibility guidelines.

• ABC Fire Extinguishers: 10lb fire extinguishers were installed in key locations for immediate response to small fires.

Reliable Communication:

• AT&T LTE Cellular Communicator: Ensures a reliable, dedicated connection to our 24/7 monitoring station, independent of phone lines.

• Surge Protection: A robust surge protector was installed to safeguard the system's critical communication components.

PROJECT OUTCOME

Fire Alarm Houston successfully installed and commissioned a state-of-the-art fire alarm system that meets all local and national fire codes. The Maryam Islamic Center is now equipped with a robust and reliable life-safety infrastructure, providing peace of mind to its leadership and the entire community that uses the facility.
